HOME PAGE > EQUIPMENT > Secondary Measurement Testing > NAFJ Series Surge Arrester Discharge Counter Calibrator
NAFJ Series Surge Arrester Discharge Counter Calibrator
  • Equipment Name： NAFJ Series Surge Arrester Discharge Counter Calibrator

NAFJ Series Surge Arrester Discharge Counter Calibrator
Product introduction
NAFJ Series Arrester Discharge Counter Detector Applies to test if the discharge counter normally work.
Also called name
Arrester discharge counter tester, discharge counter tester, discharge counter calibrator, lightning counter validator, lightning counter calibrator,Surge Arrester Discharge Counter detector, NAFJ Series Surge Arrester Discharge Counter Calibrator
The Characteristics of the products
Small size and light weight
The parameters of the products
Project parameters Model
NAFJ NAFJ
Input voltage AC220V ±10%  50Hz
Output voltage 0～1600V
Accuracy 2%  (According to requirements higher voltage)
Impulse current ＞100A（8/20μS）
Charging time
≤30S
Power concumption ＜30VA
Battery charging - 6～8 hours
Dimension 320mm×240mm×150mm
