NAMIC lightning impulse generator high voltage withstand voltage pulse voltage power source

Also called name

Lightning impulse generator voltage source, impulse generator pulse power supply, lightning impulse pulse voltage source, lightning impulse generator pulse power supply, pulse voltage source, lightning pulse voltage source, impulse pulse voltage source, impulse pulse power supply

Equipment usage

NAMIC high-voltage withstand pulse voltage source can realize square wave output or DC output through charging and discharging working mode. This equipment is suitable for power systems, industrial and mining enterprises, scientific research institutes, professional colleges, and protection manufacturers.
NAMIC's high-voltage withstand pulse voltage source is portable and suitable for field testing.


Main Technical parameters

Working power supply voltage: AC220V±10% 50HZ
Output waveform: square wave pulse
Temperature range: -10℃～＋75℃
Relative humidity: 0～85%
Maximum peak withstand current: 10A
Positive and negative pulse width: 3ms-5ms
Working power supply: 220V±15% 50Hz
Output voltage: 0-1kV, continuously adjustable.


Device communication method

Compatible with Mitsubishi PLC communication protocol.
