NASMG Three phase Power Check Meter

Product introduction
NASMG Three-phase Meter is checked for three-phase electrical parameter measurement, protection circuit CT wiring correctness analysis and three-phase voltage and current imbalance detection instruments, you can complete the three-phase voltage, current, phase angle, frequency, power, power factor and other electrical parameters of the high-precision measurement, the more unique is to analyze the accuracy of CT wiring electricity balance checking power lines, and has a power calculation functions.
NASMG three-phase electricity tester is designed with high-speed ARM processor as the next machine measurement of electrical parameters, fully graphical interface, true color display, touch screen operation, friendly interface, easy to carry equipment and powerful.

Also called name
Multifunction electricity tester, multi-phase electrical tester, electrical tester, three-phase multi-function electrical tester, multifunction power detector

The Characteristics of the products
1, Three-phase electricity tester simultaneously measure 1-3 way AC voltage
2, While measuring 1-4 way AC current (including zero-phase current)
3, The measured voltage, the current, the voltage and current between phase
4, The measuring grid frequency
5, The measurement of active, reactive and apparent reactive power
6, The measured power factor
7, Analyze the correctness of CT wiring and wiring errors discriminant power meter
8, Three-phase three-wire two components meter 192 kinds of wiring error detection and determination, and gives the vector diagram, wiring diagrams, power expressions and text description
9, Three-phase power voltage and current imbalance detection
10, The measured phase voltage range :5-500V, phase current measuring range: 5mA-10A
11, Showing hexagonal vector graphics
12, As the leakage current meter
13, Low-power design, the longest time up to 12 hours continuous use
14, Auto range, touch screen buttons humanized design
15, U-disk data storage can be exported user data processing

The parameters of the products

Type	Testing Range	Unit	Error	Resolution
Voltage	1～500	V	0.2%	0.01V
Current	0.001～10	A	0.2%	0.0001A
active power	0.001～5k	W	0.5%×reading(PF=1)	0.1W
reactive power	0.001～5k	VAR	0.5%×reading (PF=0)	0.1VAR
Apparent power	0.001～5k	VA	0.5%×reading	0.1VA
Frequency	45～65	HZ	0.1%×reading	0.01HZ
phase	0～360	°	±1°	0.1°

Note: 1mA-5mA at ± 3 °
