NASBF Series Third-harmonic Generator

Product introduction
NASBF series third-harmonic generator is utilize the saturation characteristics of magnetic circuit, remove the maximum three harmonic voltage from the device, for the induction coil type electrical product, make a turn to turn, segment to segment, and level to level frequency doubling and voltage doubling testing, so as to check the insulation withstand voltage level.

Also called name
Third harmonic generator, inductive voltage third-harmonic generator, third-harmonic generator power supply generator, trial third harmonic transformer device, third-harmonic inductive withstand generator,  third-harmonic trial generator, third-harmonic testing device, third-harmonic inductive withstand device, voltage transformer frequency doubling AC withstand testing device.

The Characteristics of the products
1, NANAO Electrical produced NASBF series third-harmonic generator, simple to operate, with reliable performance
2, Satisfy the need of transformers and inductors inductive withstand.

The parameters of the products
Input Capacity :5-200KVA
Output capacity :1-40KVA
Input voltage: Three-phase AC380V
Output voltage: 0 ~ 300V; 0-500V; 0-800V; 0-1000V
Input Frequency: 50Hz
Output frequency: 150Hz
Structure: less than 2000A as a whole or split instruction, more than 2000A is split instruction .
