NAZCS Insulation Resistance Tester
Product introduction
Insulation resistance in proportion to the pressing time during the testing of the large capacity power equipment, longer pressing time maks higher insulation resistance. This phenomenon called absorption phenomenon of insulation. To understand the insulation performance of the test product, firstly, must do its absorption ratio and polarization index test for the next leak , dielectric loss , partial discharge , etc., insulation performance tests to provide security. Nanao Electric Wuhan Electric Co., Ltd. in accordance with standardized protocols special launch NAZCS Power Smart insulation resistance tester ( hereinafter referred to as NAZCS), for electrical equipment for insulation, absorption ratio, polarization index test, insulation test for the series provide an initial accurate judgments.

Also called name
Intelligent Insulation resistance tester, insulation resistance tester intelligent, insulation resistance tester, insulation resistance tester, NAZCS Insulation Resistance Tester

The Characteristics of the products
1 This instrument uses advanced MCU control processes, human-machine interface dialogue, easy to carry, easy to operate; enclosed battery, AC-DC, and has under-voltage protection and battery overcharge protection. The instrument can automatically display the current time, save 8 group of historical test data and time for the trial to provide a great convenience.
2.NAZCS short-circuit current is more than 3mA, to overcome the common type megger short circuit current is small, the test is not accurate, vulnerable to interference and other defects.
3.NAZCS do division by sampling voltage and current timely, this way ensuring the accuracy of the resistance value not influence by the unstable voltage during the test process.

The parameters of the products
1, the output voltage:-DC500V,-DC1000V,-DC2500V,-DC5000V
Error: ± 5% FS (FS is the full scale value);
2, the short-circuit current:> 3mA
3, test accuracy
5 ~ 100MΩ error: ± 5% FS (FS is the full scale value);
100 ~ 10GΩ error: ± 5% FS (FS is the full scale value);
10 ~ 200GΩ error: ± 10% FS (FS is the full scale value);
≧ 200GΩ error: ± 20% FS (FS is the full scale value);
4, conditions of use
Ambient temperature: 0 ℃ -40 ℃
Relative humidity: ≤ 70% RH
5, power scope
AC: 220V ± 10%
6, the size and weight
Dimension: 280mm × 210mm × 100mm;
Weight: <3kg
