NAHLY 600A Contacts (circuit) resistance tester
Product introduction
Used for a variety of high voltage circuit breakers (referred to as switch) main contact contact resistance measurements, you can also test the high voltage cable lines, busbars, weld and any low resistance non-inductive electrical resistance values, etc.
Accordance with the latest standards "JJG1052-2009 loop resistance test procedures" GB50150-91 and DL/T596-1996 the relevant regulations, can be a long stable output of not less than 100A large current, the instrument can not be avoided continuous work and thus can not effectively breakdown "oxide film" of the state. Using the new power and precision measurement and control circuits combined, making the measurement data with high accuracy and good reproducibility.
Also called name
Loop resistance tester, contact resistance tester, switch loop resistance tester, the contact loop resistance tester, touch (loop) resistance tester
The Characteristics of the products
1. large electric current: Using the latest Power technology to a long continuous output high current pulsed power to overcome the drawbacks of the instantaneous current can effectively switch contacts oxide film breakdown, get good test results.
2. anti-interference ability: In severe interference conditions, the LCD screen can be stabilized at last a data ± 1 digit range, the reading is stable and repeatable.
4. long life: all precision resistors, the effective elimination of ambient temperature on measurement results, while enhancing the use of military connectors vibration resistance.
5. Easy to carry: small size, light weight.
The parameters of the products

ITEM	NAHLY-100A		NAHLY-200A		NAHLY-100B		NAHLY-200B
Test current	50A，100A		100A，200A		50A，100A		100A，200A
Measure range	50A	0~2000μΩ	100A	0~2000μΩ	50A	0~4000μΩ	100A	0~2000μΩ
	100A	0~2000μΩ	200A	0~2000μΩ	100A	0~2000μΩ	200A	0~2000μΩ
Display mode	3 and half LCD display				LCD Display
resolution	0.1μΩ				0.01μΩ
Store data	no				Can store 80 group test data
Time function	no				With timing function
Current display	Can't display the size of output current				Can display real output current value
Print function	no				With print function
USB interface	no				with USB interface
External connection PC	no				Can download the tested data to PC for analysis
Precision	≤0.5%
Power supply	AC220×(1±10%)V;50×（1±5%）Hz
Operation temp	0℃ - 45℃(no condensing)
Relative humidity	≤ 90%RH
Altitude	≤ 1000m
Out Dimension	290×260×215mm		360×290×245mm		330×280×215mm		330×280×290mm
Weight	5.8kg		9.5kg		7.7kg		8.9kg
